Onga 417 High Flow Corrosion-Resistant Centrifugal Chemical Transfer Pump

High flow centrifugal transfer pump, corrosion-resistant construction, wide operating range, heavy-duty performance

The Onga 417 Centrifugal Pump is a high-performance water transfer pump engineered for demanding domestic, agricultural, and industrial applications. Constructed using high-grade corrosion-resistant materials, it ensures durability and long service life even in challenging environments.

Featuring an advanced high-efficiency impeller, the pump delivers strong and consistent flow performance across a wide operating range. It is particularly suited for applications requiring both high flow and higher head capability compared to smaller models in the series.

The pump utilizes a single-stage centrifugal design for smooth and efficient operation. It is equipped with a totally enclosed fan-cooled (TEFC) motor and built-in thermal overload protection, ensuring safe operation and protection against overheating.

Designed as a compact, surface-mounted unit, the Onga 417 is easy to install and maintain. It is suitable for pumping clean, non-aggressive liquids without solids or fibres, making it ideal for a wide range of fluid transfer applications.

Key Features

• High flow centrifugal pump design

• Corrosion-resistant construction materials

• Wide performance range for varied applications

• Single-stage surface-mounted configuration

• Built-in thermal overload protection

• Totally enclosed fan-cooled (TEFC) motor

• Reliable and low-maintenance operation

• Compact and easy to install

Applications

• Water transfer systems

• Agriculture and irrigation

• Hydroponics and nutrient delivery

• Tank filling and hose down

• Industrial fluid transfer

• Garden watering and sprinkler systems

Technical Specifications

• Model: 417
• Pump Type: Centrifugal (Single Stage)
• Power Supply: 230V, 1 Phase, 50 Hz
• Motor Power: 0.75 kW (P1) / 0.67 kW (P2)
• Speed: 2900 RPM
• Current: 4.1 A
• Maximum Flow Rate: Up to 176 L/min
• Maximum Head: Up to 26 m
• Maximum Working Pressure: 410 kPa
• Maximum Liquid Temperature: 70°C

• Minimum Liquid Temperature: 1°C
• Maximum Ambient Temperature: 55°C
• Motor Protection: Automatic Thermal Overload
• Insulation Class: B

• Protection Rating: IPX5
• Inlet/Outlet: 1” BSP (Male)
• Construction Materials:

• Pump Casing: Glass-filled ABS

• Impeller: Glass-filled Polycarbonate

• Seal: Nitrile / Ceramic / Carbon

• Shaft Components: Stainless Steel / Mild Steel
